BK-ALU-0004-001

BK-ALU-0004-001
Product Name : BK-ALU-0004-001
Product Description

Place of Origin: Taiwan

Brand Name: Broadlake

Type: SMD, TO220, TO218

Material: AL5052, T=0.8mm

Packaging Details: Carton / Pallet


Q'ty :
    Enlargement



    Product Character



        BROADLAKE CO ., LTD.


    Part Number BK-ALU-0004-001
    Material AL5052 T=0.8mm
    Finish  Black Anodized
    Certification ISO9001:2015,REACH,RoHS2002/95/EC
    Field

    1. Stamped Heat Sink for Transistor Package

    2. Electronic Components

    3. Switching Power Supply

        Standard Heatsink for TO-220&TO-218 packages

        Mounted on the device by means of vertical horizontal direction

    Capability

    Max. 250T Press Machine

    Sample Contact us
    Dimension            proimages/01-EMS/2-STAMPING_Drawing/1-只有浮水印/BK-ALU-0004-001_draw(400).jpg
